PatternSmith is a 2D drafting system built specifically for textile pattern creation and management. Organize and nest patterns. Import files from other systems and export files to your cutting machine.
2D Pattern Drafting and Editing
– Geometric creation tools – Lines, arcs, freeform curves, polygons, etc
– Textile-specific entities – Notches, seams, anchors, etc
– Editing tools with previews
– Optimize imported patterns for smooth, fast cutting
Digitizing
– Trace over image files
– CadShot and CadShot Mobile (Add-On Software)
Project Management
– Keep all patterns for a product in an organized project file
Parametric Design (Templates Add-On)
Streamlined Order Processing (Workflow Add-On)
Material Library
Nesting
– Manual
– Automatic (add-on feature)
Import Types:
– DXF, AAMA, Eastman CMD, Gerber GBR, NC and ISO, Encapsulated Postscript EPS
Export Types:
– DXF, Eastman CMD, Gerber GBR
PatternSmith
Award-Winning Pattern Drafting, Editing & Nesting Software
- Maximum Power ~ Minimum Complication
- Intuitive and Powerful
- Full 2D CAD Pattern Drafting
- File Import / Export
- Automated Pattern Clean-up
- Embedded Help Files
- Quickstart Guide with Tutorials
- Video Tutorials
- Digitizing
- Custom add-ons for greater efficiency
- And many more powerful features…
